HTTP Protocol

HTTP Features

  • Persistent Connection (HTTP/1.1): TCP connection is maintained without explicit disconnection
    • Both server and client must support it
    • Uses keep-alive header
  • Pipelining: When multiple requests are needed, send all requests before receiving responses (useful for loading scripts and images in HTML documents)
  • Range Request: Partial download for resume functionality
  • Content Negotiation
    • Server-driven negotiation
    • Agent-driven negotiation (user decides)
    • Transparent negotiation (mix of both)

HTTP Request

HTTP Methods

  • GET: Retrieve resource
  • POST: Send entity
  • PUT: Transfer file
  • HEAD: Get message headers only
  • DELETE: Delete file
  • OPTIONS: Query available methods
  • TRACE: Trace route
  • CONNECT: Request tunneling from proxy

Request Message Structure

Components: Method, URI, Protocol Version, Request Headers, Entity

POST /form/entry HTTP/1.1
Host: hackr.jp
Connection: keep-alive
Content-Type: application/x-www-form-urlencoded
Content-Length: 16

name=ueno&age=37

GET /index.html HTTP/1.1
Host: www.hackr.jp

POST Method Content Types (MIME types)

multipart/form-data

  • Use when you have binary (non-alphanumeric) data or a significantly sized payload
  • Has overhead for short alphanumeric values

application/x-www-form-urlencoded

  • Use for regular form data
  • Not suitable for byte values
  • Reserved and non-alphanumeric characters are replaced by %HH (percent sign and two hexadecimal digits representing the ASCII code)
  • This can triple the size for binary data

HTTP Response

Response Message Structure

Components: Protocol Version, Status Code, Status Description, Response Headers, Body

HTTP/1.1 200 OK
Date: Tue, 10 Jul 2012 06:50:15 GMT
Content-Length: 362
Content-Type: text/html

<html>
...

Common Status Codes

  • 200 OK: Request succeeded
  • 400 Bad Request: Invalid request

Curl - API Testing Tool

Basic Usage

curl http://localhost:9091/messagePattern

Options

  • -G: GET request
  • -v: Verbose output
  • --data-urlencode: Encode query parameters

Examples

Basic Authentication

curl --user daniel:secret http://example.com/

URL Encoding

curl -G -v http://localhost:3000/ --data-urlencode "query=word"
# Results in: http://localhost:3000/?query=word

POST with JSON Body

curl -X POST http://localhost:9091/api/users \
  -H "Content-Type: application/json" \
  -d '{"name":"John","age":30}'

File Upload

curl -X POST http://localhost:9091/upload \
  -F "file=@/path/to/file.png" \
  -F "description=profile image"

Custom Headers

curl -H "Authorization: Bearer token123" \
     -H "Accept: application/json" \
     http://localhost:9091/api/resource

HTTP Versions Comparison

Understanding the differences between HTTP versions helps you choose the right configuration for your applications.

HTTP/1.0

  • One request per TCP connection
  • Connection closes after each response
  • No persistent connections by default

HTTP/1.1

  • Persistent connections (keep-alive) by default
  • Pipelining support (send multiple requests without waiting)
  • Chunked transfer encoding
  • Host header required (enables virtual hosting)

HTTP/2

  • Binary protocol instead of text-based
  • Multiplexing: multiple requests over a single TCP connection simultaneously
  • Header compression (HPACK)
  • Server push: server can proactively send resources
  • Significantly faster for loading web pages with many resources

HTTP/3

  • Uses QUIC protocol instead of TCP (built on UDP)
  • Faster connection establishment
  • Better handling of packet loss
  • Built-in encryption (TLS 1.3)

Common HTTP Headers

Request Headers

Header Purpose Example
Host Target domain Host: www.example.com
Authorization Authentication credentials Authorization: Bearer token
Accept Expected response format Accept: application/json
User-Agent Client identification User-Agent: Mozilla/5.0...
Cache-Control Caching directives Cache-Control: no-cache

Response Headers

Header Purpose Example
Content-Type Body media type Content-Type: text/html
Set-Cookie Set browser cookies Set-Cookie: id=abc; Path=/
Location Redirect URL Location: /new-page
Access-Control-Allow-Origin CORS policy Access-Control-Allow-Origin: *

Status Code Categories

Range Category Description
1xx Informational Request received, continuing process
2xx Success Request successfully received and processed
3xx Redirection Further action needed to complete request
4xx Client Error Request contains bad syntax or cannot be fulfilled
5xx Server Error Server failed to fulfill a valid request

Most Common Status Codes

  • 200 OK: Standard success response
  • 201 Created: Resource successfully created (common for POST)
  • 301 Moved Permanently: Resource permanently moved (SEO redirect)
  • 302 Found: Temporary redirect
  • 400 Bad Request: Malformed request syntax
  • 401 Unauthorized: Authentication required
  • 403 Forbidden: Server understood but refuses to authorize
  • 404 Not Found: Resource does not exist
  • 500 Internal Server Error: Generic server error
  • 502 Bad Gateway: Invalid response from upstream server
  • 503 Service Unavailable: Server temporarily overloaded or under maintenance
