Authentication Methods

OAuth

  • Allows apps to get information from user’s account without password
  • Uses bearer token type

Basic Access Authentication

JWT Token

  • Uses HTTP headers like Referer and Origin to reject requests from unauthorized sources
  • JWT Explanation

OAuth Authorization Code Grant Flow

Simple Flow Overview

  1. User initiates Google login from a client app
  2. App server generates authorizeUrl and sends to client
  3. Client opens authorizeUrl in browser
  4. User logs in to Google in browser
  5. Browser redirects to redirect_url (app server URL)
  6. App server receives code and state via redirect_url
  7. App server requests access token from Google using code and state
  8. Access Google resources with accessToken

Detailed Flow

Step 1: App Request to Server

The app sends OAuth authentication request to app server via web browser with:

  • Server URL: If modified by attacker, requests could go to attacker’s server
  • OAuth Server Name: (Google, Facebook, etc.)
  • Redirection URL: Deep link defined by app
  • Platform: Deep link behavior varies by platform
  • Package Name: Required for Android deep links

Security Warning

When logging in, users should check:

  • Which site is requesting OAuth
  • What permissions are being requested

Step 2-3: Server Processes Request

  • providerLookup is called to get OAuth2ServerSettings
  • urlProvider sets where to receive results after Google auth (server URL + required queries)
  • Server sends 302 redirect to Google’s authorizeUrl

Step 4-6: Authentication Flow

  • User logs in to Google
  • Client receives code + status
  • Server includes redirect_uri when redirecting to Google
  • After login, Google redirects client to that URI

Step 7-8: Token Exchange

  • Client sends status + code to redirected app server
  • App server requests access token from accessTokenUrl
  • Server creates principal containing access token

Step 9: Profile Retrieval

  • Call https://www.googleapis.com/userinfo/v2/me with access token
  • Get user’s unique ID from profile info
  • OAuth login complete

Step 10: Service Token

  • Send redirect response to client with service token

InstalledAppFlow

First Run

  • Google login window appears for authentication
  • After authentication, Access Token and Refresh Token are saved to token.json

Subsequent Runs

  • If Access Token in token.json is valid, use it
  • If expired, request new Access Token using Refresh Token

Security Considerations

Token Storage Best Practices

Storage Location Security Level Use Case
HTTP-only Cookie High Web applications (server-rendered)
Secure Cookie + SameSite High Web apps with CSRF protection
Memory (variable) Medium SPAs during session only
localStorage Low Not recommended for sensitive tokens
sessionStorage Low-Medium Better than localStorage, cleared on tab close

Never store access tokens or refresh tokens in localStorage for production applications. An XSS attack can easily read localStorage values. HTTP-only cookies are the safest option for web applications because JavaScript cannot access them.

Common Security Vulnerabilities

CSRF (Cross-Site Request Forgery)

  • Attacker tricks the user’s browser into making authenticated requests
  • The state parameter in OAuth prevents this by verifying that the request originated from your application
  • Always validate the state parameter when receiving the callback

Token Leakage

  • Tokens in URL query parameters can be logged in server logs, browser history, and referrer headers
  • Use POST requests for token exchange instead of GET
  • Use short-lived access tokens (5-15 minutes) with longer-lived refresh tokens

Redirect URI Manipulation

  • Always register exact redirect URIs in your OAuth provider settings
  • Avoid wildcard redirect URIs
  • Validate that the redirect URI in the callback matches the registered URI

OAuth Scopes

Scopes define what resources and operations the application can access on behalf of the user.

Google OAuth Common Scopes

Scope Access Granted
openid User’s basic identity
profile Name, profile picture
email Email address
https://www.googleapis.com/auth/drive.readonly Read Google Drive files
https://www.googleapis.com/auth/calendar Full calendar access

Best Practices for Scopes

  • Request only the minimum scopes your application needs (principle of least privilege)
  • Request scopes incrementally as features are used, not all at once during initial login
  • Clearly explain to users why each permission is needed

Token Refresh Flow

Access tokens are intentionally short-lived for security. When an access token expires, the refresh flow is:

  1. Client sends a request with an expired access token
  2. Server responds with 401 Unauthorized
  3. Client sends the refresh token to the token endpoint
  4. Server validates the refresh token and issues a new access token
  5. Client retries the original request with the new access token

If the refresh token itself has expired or been revoked, the user must go through the full OAuth login flow again.

Handling Token Refresh in Code

A common pattern is to implement an HTTP interceptor that automatically handles token refresh:

Request → Check if token expired → If yes, refresh → Retry request
                                 → If refresh fails → Redirect to login

This ensures a seamless user experience where the user does not need to re-login unless absolutely necessary.

OAuth 2.0 Grant Types

OAuth 2.0 defines several grant types for different use cases. Choosing the right one depends on your application type.

Authorization Code Grant (with PKCE)

This is the recommended flow for most applications, including SPAs and mobile apps. PKCE (Proof Key for Code Exchange) adds an extra security layer to prevent authorization code interception attacks.

How PKCE Works

  1. Client generates a random code_verifier string
  2. Client creates a code_challenge by hashing the verifier with SHA-256
  3. Client sends the code_challenge with the authorization request
  4. When exchanging the authorization code for tokens, client sends the original code_verifier
  5. Server verifies that the hash of code_verifier matches the original code_challenge

This prevents an attacker who intercepts the authorization code from exchanging it for tokens, because they don’t have the original code_verifier.

Client Credentials Grant

Used for server-to-server communication where no user is involved. The client authenticates directly with its own credentials.

POST /token
Content-Type: application/x-www-form-urlencoded

grant_type=client_credentials
&client_id=YOUR_CLIENT_ID
&client_secret=YOUR_CLIENT_SECRET
&scope=read:data

Common use cases:

  • Background services accessing APIs
  • Microservice-to-microservice authentication
  • Automated scripts and cron jobs

Device Authorization Grant

Used for devices with limited input capabilities (smart TVs, IoT devices, CLI tools). The user authenticates on a separate device (phone or computer).

  1. Device requests a user code and verification URL
  2. Device displays the URL and code to the user
  3. User navigates to the URL on their phone/computer and enters the code
  4. Device polls the token endpoint until the user completes authentication

Implementing OAuth in Practice

Server-Side Implementation (Node.js Example)

const express = require('express');
const axios = require('axios');
const crypto = require('crypto');

const app = express();

// Step 1: Redirect to OAuth provider
app.get('/auth/google', (req, res) => {
    const state = crypto.randomBytes(16).toString('hex');
    // Store state in session for validation
    req.session.oauthState = state;

    const params = new URLSearchParams({
        client_id: process.env.GOOGLE_CLIENT_ID,
        redirect_uri: 'https://yourapp.com/auth/callback',
        response_type: 'code',
        scope: 'openid profile email',
        state: state,
    });

    res.redirect(`https://accounts.google.com/o/oauth2/v2/auth?${params}`);
});

// Step 2: Handle callback
app.get('/auth/callback', async (req, res) => {
    const { code, state } = req.query;

    // Validate state parameter
    if (state !== req.session.oauthState) {
        return res.status(403).send('Invalid state parameter');
    }

    // Step 3: Exchange code for tokens
    const tokenResponse = await axios.post(
        'https://oauth2.googleapis.com/token',
        {
            code,
            client_id: process.env.GOOGLE_CLIENT_ID,
            client_secret: process.env.GOOGLE_CLIENT_SECRET,
            redirect_uri: 'https://yourapp.com/auth/callback',
            grant_type: 'authorization_code',
        }
    );

    const { access_token, refresh_token, id_token } = tokenResponse.data;

    // Step 4: Get user info
    const userInfo = await axios.get(
        'https://www.googleapis.com/oauth2/v2/userinfo',
        { headers: { Authorization: `Bearer ${access_token}` } }
    );

    // Create session or JWT for your application
    // ...
});

Common Implementation Mistakes

1. Not Validating the State Parameter

The state parameter prevents CSRF attacks. Always generate a unique, unpredictable value, store it in the session, and validate it when receiving the callback.

2. Storing Tokens Insecurely

Never store tokens in localStorage for production apps. Use HTTP-only cookies with the Secure and SameSite flags, or keep tokens in memory only.

3. Not Implementing Token Rotation

When issuing a new access token using a refresh token, also issue a new refresh token and invalidate the old one. This limits the window of exposure if a refresh token is compromised.

4. Requesting Too Many Scopes

Only request the permissions your app actually needs. Requesting excessive scopes makes users less likely to approve the authorization request and increases the risk if tokens are compromised.

OpenID Connect (OIDC)

OpenID Connect is an identity layer built on top of OAuth 2.0. While OAuth 2.0 only handles authorization (what can I access?), OIDC adds authentication (who am I?).

Key Differences from OAuth 2.0

Feature OAuth 2.0 OIDC
Purpose Authorization Authentication + Authorization
Token Access Token Access Token + ID Token
User Info Separate API call needed Included in ID Token (JWT)
Standard Claims None Name, email, picture, etc.

ID Token

The ID Token is a JWT that contains claims about the authenticated user:

{
  "iss": "https://accounts.google.com",
  "sub": "110169484474386276334",
  "aud": "YOUR_CLIENT_ID",
  "exp": 1711234567,
  "iat": 1711230967,
  "email": "user@example.com",
  "name": "John Doe",
  "picture": "https://example.com/photo.jpg"
}

Always validate the ID Token on your server: verify the signature, check the iss (issuer), aud (audience), and exp (expiration) claims.
