CDN (Content Delivery Network)

What is CDN?

CDN allows CDN providers to deliver content that doesn’t change frequently from servers to users.

How it Works

  1. User makes a request to the server
  2. DNS server redirects to CDN provider’s server
  3. CDN delivers cached content from the nearest server to the user

Benefits

  • Faster delivery: Content served from geographically closer servers
  • Reduced server load: Main server doesn’t handle all requests
  • Better performance: Cached content is served quickly

HTTP Caching

Effective caching strategies can significantly improve website performance.

Cache-Control Headers

The Cache-Control header is the primary mechanism for controlling HTTP caching behavior.

Common Directives

Directive Meaning
public Response can be cached by any cache (browser, CDN, proxy)
private Response can only be cached by the browser, not shared caches
no-cache Must revalidate with server before using cached version
no-store Do not cache the response at all
max-age=3600 Cache is valid for 3600 seconds (1 hour)
s-maxage=86400 Shared cache (CDN) max age, overrides max-age for CDN
must-revalidate Cache must verify stale responses with origin server
immutable Content will never change, browser should never revalidate

Example Headers

# Static assets that rarely change (cache for 1 year)
Cache-Control: public, max-age=31536000, immutable

# API responses (no caching)
Cache-Control: no-store

# HTML pages (revalidate every time)
Cache-Control: no-cache

# User-specific content
Cache-Control: private, max-age=300

ETag and Conditional Requests

ETags enable efficient cache validation without downloading the full resource again.

How ETags Work

  1. Server sends response with an ETag header (a hash or version identifier):
    ETag: "abc123"
  2. Browser caches the response along with the ETag
  3. On the next request, browser sends:
    If-None-Match: "abc123"
  4. If the resource has not changed, server responds with 304 Not Modified (no body)
  5. If changed, server sends the new resource with a new ETag

This saves bandwidth because the server only sends the full response when the content has actually changed.

CDN Cache Invalidation

One of the most challenging aspects of using a CDN is cache invalidation — ensuring users see updated content when you deploy changes.

Strategies

  1. Cache Busting with File Hashing: Append a hash to filenames (e.g., app.a1b2c3.js). When content changes, the filename changes, and the CDN fetches the new file.

  2. Purge/Invalidation API: Most CDN providers offer APIs to manually invalidate cached content:
    • AWS CloudFront: CreateInvalidation
    • Cloudflare: Purge Cache
    • Fastly: Instant Purge
  3. Short TTL for Dynamic Content: Use short max-age values for content that changes frequently, and long TTLs for static assets.

Best Practice: Versioned Static Assets

# HTML (short TTL, always check for updates)
index.html → Cache-Control: no-cache

# CSS/JS (long TTL, filename changes on deploy)
app.v2.1.0.js → Cache-Control: public, max-age=31536000, immutable
styles.a3f8b2.css → Cache-Control: public, max-age=31536000, immutable

# Images (medium TTL)
logo.png → Cache-Control: public, max-age=86400

This approach ensures that HTML always fetches the latest asset URLs, while static files are cached aggressively because their filenames change when content changes.

CDN Providers Comparison

Provider Strengths Best For
CloudFront Deep AWS integration AWS-based infrastructure
Cloudflare Free tier, DDoS protection, easy setup Small to medium websites
Fastly Real-time purging, edge computing Dynamic content, APIs
Akamai Largest network, enterprise features Large enterprises

Browser Caching Behavior

Understanding how browsers handle caching is essential for web developers. Different browsers may have slight variations, but the general behavior follows the HTTP specification.

Cache Lifecycle

When a browser receives a response with caching headers, it goes through this decision process for subsequent requests:

  1. Check if cache entry exists for the URL
  2. Check if it’s fresh (within max-age or before Expires)
  3. If fresh: Use cached version without contacting server
  4. If stale: Send conditional request (with If-None-Match or If-Modified-Since)
  5. If 304 Not Modified: Use cached version
  6. If 200 OK: Replace cache with new version

Stale-While-Revalidate

The stale-while-revalidate directive allows the browser to immediately serve a stale cached response while revalidating in the background:

Cache-Control: max-age=3600, stale-while-revalidate=60

This means: cache is fresh for 1 hour. After that, serve the stale version for up to 60 more seconds while fetching the new version in the background. This provides a better user experience because users never have to wait for revalidation.

Vary Header

The Vary header tells caches that the response varies based on certain request headers. This is important for content negotiation.

Vary: Accept-Encoding, Accept-Language

CDNs cache different versions of the same URL based on these headers. For example, a gzipped version and a non-gzipped version are cached separately.

Service Workers and Caching

Service Workers provide programmatic control over caching, allowing you to implement sophisticated offline-first strategies.

Cache-First Strategy

// Good for static assets that rarely change
self.addEventListener('fetch', (event) => {
    event.respondWith(
        caches.match(event.request).then((response) => {
            return response || fetch(event.request);
        })
    );
});

Network-First Strategy

// Good for dynamic content where freshness matters
self.addEventListener('fetch', (event) => {
    event.respondWith(
        fetch(event.request)
            .then((response) => {
                const clone = response.clone();
                caches.open('dynamic-cache').then((cache) => {
                    cache.put(event.request, clone);
                });
                return response;
            })
            .catch(() => caches.match(event.request))
    );
});

Stale-While-Revalidate Strategy

// Serve cached content immediately, update cache in background
self.addEventListener('fetch', (event) => {
    event.respondWith(
        caches.match(event.request).then((cached) => {
            const fetchPromise = fetch(event.request).then((response) => {
                caches.open('sw-cache').then((cache) => {
                    cache.put(event.request, response.clone());
                });
                return response;
            });
            return cached || fetchPromise;
        })
    );
});

CDN Configuration Examples

AWS CloudFront

{
    "CacheBehaviors": {
        "DefaultCacheBehavior": {
            "ViewerProtocolPolicy": "redirect-to-https",
            "CachePolicyId": "658327ea-f89d-4fab-a63d-7e88639e58f6",
            "Compress": true
        }
    }
}

Key settings for CloudFront:

  • Origin Shield: Additional caching layer to reduce load on your origin
  • Lambda@Edge: Run code at CDN edge locations for dynamic content manipulation
  • Price Class: Control which edge locations to use (affects cost and coverage)

Cloudflare Page Rules

URL: example.com/static/*
Cache Level: Cache Everything
Edge Cache TTL: 1 month
Browser Cache TTL: 1 year

URL: example.com/api/*
Cache Level: Bypass

Measuring Cache Performance

Key Metrics

Metric Description Target
Cache Hit Ratio Percentage of requests served from cache > 90%
TTFB Time to First Byte < 200ms
Origin Offload Percentage of requests NOT reaching origin > 85%
Bandwidth Savings Data served from cache vs. total > 80%

Checking Cache Status

Most CDNs add response headers indicating cache status:

# CloudFront
X-Cache: Hit from cloudfront

# Cloudflare
CF-Cache-Status: HIT

# Fastly
X-Cache: HIT

These headers are invaluable for debugging caching issues. When you see MISS, it means the CDN had to fetch from the origin. When you see HIT, the content was served from the CDN cache.

Common Caching Pitfalls

  1. Caching user-specific content: Never cache responses that contain personal data with Cache-Control: public. Always use private for authenticated content.

  2. Forgetting to set Vary headers: If your server returns different content based on Accept-Language but doesn’t set Vary: Accept-Language, CDNs may serve the wrong language to users.

  3. Overly aggressive caching of HTML: HTML pages should typically use no-cache so the browser always checks for updates. Static assets referenced by HTML can be cached aggressively with content hashing.

  4. Not invalidating after deploys: If you update a CSS file but keep the same filename and long cache TTL, users will see the old version. Always use content hashing or cache busting for static assets.

  5. Ignoring mobile vs. desktop: If your site serves different content for mobile and desktop users, make sure to include Vary: User-Agent or use separate URLs.
