Android Development Process

API Development

  1. Design API request/response (JSON format)
  2. Design database, POC (Proof of Concept - verify feasibility)
  3. Define API request/response code
  4. Write API unit test code
    • Create mock data from defined JSON
    • Test proper parsing
    • Compare with actual API
  5. Implement API
  6. Test API

Database Development

  1. Define Room data model code
  2. Implement Room unit test code
  3. Implement Room
  4. Test Room

ViewModel Development

  1. Define ViewModel UI data and event method interfaces
  2. Implement ViewModel unit test code
    • Use created API response mock data
    • Test business logic
    • Test all cases defined in specifications
  3. Implement ViewModel
  4. Test ViewModel

UI Development

  1. Define UI component code (layout, dialog, fragments)
  2. Implement UI unit test code
    • Verify UI displays correctly for each case
    • Auto-screenshot for UI inspection per case
  3. Implement UI (data binding)
  4. Test UI

Development Tips

General Tips

  • Create your own TODO comments: Check for missing parts
  • Use Instant Run: Speed up development iteration
  • Test with virtual devices: Consistent testing environment
  • Avoid test device interference:
    • Avoid devices that ask for permission on every install
    • Ensure stable connection

UI Layout Tips

  • Set Guideline, Barrier, Group first
  • Then position UI components according to these guides

This approach creates more maintainable and adaptable layouts.

Collaboration Workflow

Development Order

  1. API discussion
  2. Design discussion
  3. Development

Separation of Concerns

Design

  • Verify images are correctly exported
  • Verify layout ranges are appropriate

Logic

  • Business logic implementation

Server

  • Test if API is called correctly
  • Write API call tests in app code

Integration

  • End-to-end testing

Task Division Benefits

  • Reduce duplicate work
  • Reduce knowledge requirements for each individual
  • Clear responsibility boundaries

Code Review Process

Code reviews are essential for maintaining code quality in Android development. Here is a structured approach:

What to Check During Review

Architecture and Design

  • Does the code follow the established architecture (MVVM, Clean Architecture)?
  • Are dependencies flowing in the right direction?
  • Is business logic in the ViewModel, not in the Activity/Fragment?

Code Quality

  • Are variable and function names descriptive and following naming conventions?
  • Is there any duplicated code that should be extracted?
  • Are there any memory leaks (especially with context references)?

Android-Specific Concerns

  • Is the lifecycle handled correctly? (e.g., onDestroy, configuration changes)
  • Are network calls handled on background threads?
  • Is the UI thread not blocked by heavy operations?
  • Are permissions requested properly?

Testing Strategy

Test Pyramid for Android

Level Tools Speed Scope
Unit Tests JUnit, Mockito Fast Single function/class
Integration Tests Robolectric Medium Multiple components
UI Tests Espresso, Appium Slow Full user flows

Unit Test Coverage Priorities

  1. ViewModel business logic: This is where most bugs occur
  2. Repository / data layer: Verify data transformations
  3. Utility functions: Helper methods used across the app
  4. Edge cases: Null values, empty lists, boundary conditions

Test Naming Convention

Use descriptive test names that explain the scenario:

@Test
fun `when user clicks login with empty password then show error message`() {
    // Arrange
    viewModel.setPassword("")

    // Act
    viewModel.onLoginClicked()

    // Assert
    assertEquals(LoginError.EMPTY_PASSWORD, viewModel.error.value)
}

Release Checklist

Before each release, go through this checklist:

  • All automated tests passing
  • Manual regression testing complete
  • ProGuard/R8 rules verified with release build
  • Version name and code updated
  • Release notes prepared
  • Crash reporting (Firebase Crashlytics) verified
  • Performance profiling done for key screens
  • APK/AAB size checked (compare with previous release)
  • Deep links tested
  • Backward compatibility verified (minimum SDK version)
